INSTALLATIONSAND USE
• For water circulation in swimming pool filtration system
• For clean and slightdirty water with solids in suspension
• The pump should be installed in an enclosed environment or sheltered from inclement weather

PERFORMANCE RANGE
• Flow rate up to 12.5m3/h
• Head up to 13m

OPERATING CONDITIONS
• Liquid temperature up to +50 ℃
• Ambient temperature up to +50 ℃
• Max. Working pressure 3bar
• Continuous duty

OPTIONS AVAILABLE ON REQUEST
• Special mechanical seal
• Other voltages or 60Hz frequency
• Higher or lower liquid temperatures

ELECTRIC MOTOR
• Two-pole induction motor, 50Hz (n = 2850rpm)
• Single phase 220V-240V
• Three phase 380V-415V
• With thermal protector incorporated into the winding
• Insulation class F

• Protection IP66
