OPERATING LIMITS

• Max. medium temperature+40° C
• Max. ambient temperature+40° C
• PH level from 4-10
• Maximum passage for suspended solids45
• Voltage fluctuation range: 0.9-1.1 times of the rated value
• Immersion depth from 0.5m- 5m

MOTOR INFORMATION

• Two-pole induction motor
• Single phase/three phase, 50/60hz (on demand)
• Thermal protector for single phase
• Insulation class: B
• Protection class:IPX8

MATERIAL
• Pump body: Cast iron
• Motor housing: Stainless steel
• Impeller: Cast iron
• Motor wire: Copper
• Mechanical seal: Ceramic&Graphite
• Shaft: 45#steel/stainless steel
