OPERATING LIMITS

• PH level from 6.5-8.5
• Maximum sand content is 0.1%. Passage of suspended
• Solids up to 0. 2mm
• Voltage fluctuation range:0.9-1.1 times of the rated value
• Immersion depth from 0. 5m-5m
• Max medium temperature+40°C
• Max ambient temperature+40°C

MOTOR INFORMATION

• Two-pole induction motor
• Single phase/three phase, 50/60hz (on demand)
• Thermal protector for single phase
• Insulation class: B
• Protection class:IPX8

MATERIAL
• Pump body: Cast iron
• Motor housing: Aluminum/iron
• Impeller: Aluminum
• Motor wire: Copper
• Mechanical seal: Ceramic&Graphite
• Shaft: 45#steel/stainless steel
